TCR Advanced SL 0 DA
-
Detail
Key Featured Information
Systematic Optimization
Whether it is the frame, wheels, stem, handlebars or other important parts, they are all jointly developed and designed to ensure that the entire vehicle can operate as a complete system. The most impressive modification this time is the transformation of the windward surface of the front half of the TCR, including the down tube, head tube and stem/handlebar components, all of which have been redeveloped to improve aerodynamic effects and have a clean and simple appearance and an easy-to-adjust disassembly and assembly design.
Winning efficiency
With a higher stiffness-to-weight ratio than the previous generation, as well as new aerodynamic tubes and a lighter overall weight, the new TCR provides unmatched acceleration and pedaling rigidity, helping riders win the race at the most critical moment.
Integrated aero
From the oval-section frame tubes to the new fully internal cable routing design, as well as the joint development and testing of all parts of the vehicle, a more streamlined appearance is formed, helping the flagship TCR Advanced SL 0 to increase its aerodynamic performance by 4.19W over the previous generation.
Frame geometry
Frame geometry is for reference only, please contact Giant authorized stores; dimensions may vary in different countries.
-
- XS
- 157 cm 169 cm
-
- S
- 165 cm 175 cm
-
- M
- 171 cm 181 cm
-
- ML
- 177 cm 187 cm
-
- L
- 183 cm 193 cm
-
- XL
- 189 cm 199 cm
XS S M ML L XL A Seat (Stand) Tube Length (mm) 680 710 740 770 800 830 B Seat (Stand) Tube Angle 74.5° 74.0° 73.5° 73.0° 73.0° 72.5° C Upper tube length (mm) 520 535 550 565 580 600 D Head tube length (mm) 120 130 145 165 185 200 E Head tube angle 71.0° 72.3° 73.0° 73.0° 73.0° 73.0° F Front fork (mm) 45 45 45 45 45 45 G Trail (mm) 72 64 59 59 59 59 H Front and rear wheel track (mm) 976 977 980 991 1006 1020 I Chainstay length (mm) 405 405 405 405 405 405 J Bottom bracket drop height (mm) 72 69.5 69.5 67 67 67 K Height from head to bottom bracket (mm) 517 528 545 562 581 596 L Length from head to bottom bracket (mm) 376 383 388 393 402 412 M Height from top tube to ground (mm) 703 722 743 771 798 822 N Handle width (mm) 400 400 420 420 440 440 O Faucet length (mm) 80 90 100 110 110 120 P Crank length (mm) 170 170 172.5 172.5 175 175 Q Wheel size 700C 700C 700C 700C 700C 700C -
-
